Fig. 8

Figure 8: Photographs of representative specimens of miogypsinids on polished slabs from Jamaica. 1-2, equatorial sections of Miogypsinoides companatus, sample WL5772, Chester Formation, Rio Bueno. 3, equatorial section of Miogypsina basraensis, sample WL3810, Moneague Formation, Ulster Spring. 4-10, axial (4), and equatorial (5-10) sections of Miogypsina tani from sample WL5546, Newport Formation, St Elizabeth. Scale bar = 500 µm.
